Description
● Standard materials:
Metal parts-304 stainless steel
Ball-Polypropylene
Gasket-EPDM
● Valve seals for both pressure and vacuum
● Air and water can be directed away by using plastic tube and the valves 1/8″ FNPT connection port
● All product contact surfaces have a radius of 1/4″ or better
● Valve ball is constructed of FDA, 3A approved polypropylene
● Repaire kits are available for the ball and gasket replacement
● No tools required for assembly and disassembly
● Other gasket materials available
● Maximum temperature: 212°F
● Polypropylene ball density=0.333lb/in3
● PTFE ball available (density=0.078lb/in3)
